Legero CraneBarges “Bryan” & “Michael”

Main particulars
  • 2 x Multifunctional Crane / Cargo barges for harbor duty.
  • Suitable for lifting heavy objects like anchors, fenders, heavy engine parts or other diverse cargo.
  • Highly maneuverable in restricted harbor conditions.
  • Sormec marine crane with 18 meter boom.
  • Fully sheltered cargo area.
  • Very stable design for safe loading and unloading cargo in high demanding conditions.
Description
  • Length over all 21.56 Meter
  • Width 6.25 Meter
  • Draught 1.30 Meter
  • Depth max 1.60 Meter
  • Cargo capacity 75 Tons
  • Hull 8mm Plating Twin Push bow with rubber fender all around the vessel rubber fendering
  • Service speed 8 Knots
  • Dutch Shipping Inspection: Inland waters
  • DNV 12 miles certificate
  • Rotterdam Port Authority Certificate
  • Full ADNR for dangerous goods
  • Sailing area: Inland (2006/87/EC)
Engine
  • Main Engine 380HP/280KW Caterpillar C13@1800RPM
  • Propulsion Single fixed propeller dia: 1m on shaft
  • Bow thruster 35HP/26KW
  • Generator 2 x Perkins 65 KVA
  • Hydraulics Separate Electro-Hydrauklic power pack for the crane and anchor winch
Crane & Cargo details
  • Crane Sormec Marine Crane SA/70 with 18M boom
  • Lifting capacity Safe working load (SWL) of 2 tons on 18 meters
  • Cargo hold 51 sq/m and covered by sliding hatch 4.2M x 3M
    Cargo is always transported in sheltered conditions! Cargo hold has a steel floor
  • Capacity 100 Cubic meter
  • Pallet capacity Approx. 44 pallets of 2 meter height
